JÄGER Handling has moved into it's brand new company building. The new address is:

Kocherweg 28, 74429 Sulzbach-Laufen

JÄGER Handling has moved into it's brand new company building.

The handy-lift is a ceiling-mounted, telescopic handling device.

The handy-lift is a ceiling-mounted, telescopic handling device which is designed to absorb strong moments of reaction and high payloads.

SUSPENDED

handy-lift

With this new modular construction kit you finally have a multifunctional solution for your handling devices.

The new universally usable operating handle.

FULL CONTROL

Operating Handles

The handy-flex is the proven, elevated solution for your application.

PROVEN

handy-flex

The carbo-arm is a ceiling-mounted, telescopic handling device which is designed to absorb moments of reaction.

The carbo-arm is a ceiling-mounted, telescopic handling device..

VERATILE

carbo-arm

The perfect balance is guaranteed by the spring balancers and balancers.

LIGHT AS A FEATHER

Balancer / Spring Balancer

With our verification adapter, checking your measuring sensor is child's play.

FULL CONTROL

Verification Adapter

The modular tool holder system with integrated bus system always guarantees your workers the right tools.

CONFUSION PROOF

Tool Holder System

The handy-arm is an articulated arm manipulator that can easily reach even remote screw positions due to its long range, whether from above or for underfloor applications

The handy-arm is an articulated arm manipulator .

SOLID

handy-arm

Product Portfolio

  handy-lift  chat
 handy-lift 100-500 series
telescope for installation in a ceiling guided rail system.

   handy-flex  chat
handy-flex 100-400 series
handling system movable in three axes, elevated or suspended from the
ceiling
   carbo-arm  chat
carbo-arm 055-400 series
 three-axis, flexible torque support for handheld scredrivers
    handy-arm  chat
handy-arm 500-1000 series
 articulated arm system with telescopic axle for long ranges

   operating handles  chat
start and visualization of process operations

   spring balancer / balancer  chat
spring balancer: withdrawal of working loads
 nbalancer: balancing of loads
    verification adapter  chat
simulation and countermeasurement for built-in screwdriving technology
    modular tool holder system  chat
tool holder monitoring
 worker guidance during screwdriving operations

close

item no..	index	series	max. payload [N]	torque reaction [Nm]	stroke [mm]	size spring balancer / balancer	weight [kg]
25233	4	hl100	110	Mx/My 100Nm, Mz 60Nm	350	spring balancer 9337-9340	5,6
31755	4	hl200	200	Mx/My 250Nm, Mz 160Nm	500	balancer 9356-9359	12,3
23400	2	hl300	430	Mx/My 500Nm, Mz 300Nm		balancer 9361-9366	20,1
24487	4	hl500	700	Mx/My 1000Nm, Mz 500Nm		balancer 9362-9369	27,1

item no..	index	variant	designation	code	max. payload [N]	stroke vertical [mm]	stroke horizontal [mm]	weight [kg]
31009	1	hf100	handy-flex 100	hf100	55	500	300	8,8
10003	1	hf200	handy-flex 200	hf200	80	500	300	13
10332	1	hf200d	handy-flex 200d	hf200d	80	450	300	15
23576	1	hf200c	handy-flex 200c	hf200c	70	550	300	14
27629	1	hf200dc	handy-flex 200dc	hf200dc	70	500	300	14,5
24896	4	hf200o	handy-flex 200o	hf200o	80	500	300	10
10333	1	hf300	handy-flex 300	hf300	140	500	400	17,8
10334	1	hf300d	handy-flex 300d	hf300d	140	450	400	26
27631	1	hf300c	handy-flex 300c	hf300c	140	500	300	22
27630	1	hf300dc	handy-flex 300dc	hf300dc	140	450	300	25,3
24897	2	hf300o	handy-flex 300o	hf300o	160	500	400	17,2
21721	1	hf400	handy-flex 400	hf400	750	500	450	43
21729	1	hf400d	handy-flex 400d	hf400d	710	450	500	70
46181	4	hf400c	handy-flex 400c	hf400c	750	500	450	60
24898	4	hf400o	handy-flex 400o	hf400o	750	500	450	0,01

item no..	index	designation	code	max. moment [Nm]	max. payload [N]	Hub [mm]	lmin. [mm]	lmax. [mm]	weight [kg]
25715	2	carbo-arm 055s	ca055s	55	55	659	544	1203	0,6
28116	2	carbo-arm 055m	ca055s	55	55	1058	744	1802	0,7
28115	2	carbo-arm 055l	ca055l	35	55	1458	944	1402	0,8
25409	2	carbo-arm 220s	ca220s	220	75	590	606	1196	1,2
28396	2	carbo-arm 220m	ca220m	180	75	990	806	1798	1,4
28403	2	carbo-arm 220l	ca220l	160	75	1390	1006	2396	1,5
59953	2	carbo-arm 400s	ca400s	400	210	528	672	1200	2,6
59952	2	carbo-arm 400m	ca400m	350	210	928	872	1800	2,9
59950	2	carbo-arm 400l	ca400l	300	210	1328	1072	2400	3,1

item no..	designation	code	type	max. arm length [mm]	arm height [mm]	telescopic axle	max. payload [N]
76806	handy-arm 500	ha500s	Standard	3000	2500	handy-lift 200	200
76797		ha500u	Unterflur	3000	1000
76807		ha500s	Standard	2000	2500
76805		ha500u	Unterflur	2000	1000
76806	handy-arm 750	ha750s	Standard	4000	2500	handy-lift 300	430N
76816		ha750u	Unterflur	4000	1000
76815		ha750s	Standard	3000	2500
76814		ha750u	Unterflur	3000	1000
76822	handy-arm 1000	ha1000s	Standard	4500	2500	handy-lift 500	700N
76820		ha1000u	Unterflur	4500	1000
76821		ha1000s	Standard	3500	2500
76819		ha1000u	Unterflur	3500	1000

designation	rotary switch	lever switch	axial button	two-hand- saftey- operation	presence- check	radial button 1	radial button 2	LED status indicator
e-handle [e=electronic-handle]
t-handle [t=trigger-handle]
c-handle [c=check-handle]
d-handle [d=dead-handle]
p-handle [p=pneumatic-handle]

type	code	payload [kg]	rope extension [mm]	weight [kg]
Federzug 9311-9313	FZ9311-9313	0,4-3	1600	0,6-0,8
Federzug 9320-9323	FZ9320-9323	1-8	2000	1,7-2,3
Federzug 9336-9340	FZ9336-9340	2-14	2500	3,2-3,6
Balancer 9354-9359	BA9354-9359	4-25	2000	5-6,6
Balancer 9361-9369	BA9361-9369	10-75	2000	9,9-13,9
Balancer 9370-9371	BA9370-9371	75-105	2000	16,8-17,8
Balancer 9402-9405	BA9402-9405	20-60	2000-2500	21,2-23,1
Balancer 9411-9414	BA9411-9414	60-100	2000-2500	25,6-28,5
Balancer 9422-9426	BA9422-9426	100-180	2000-2500	36,7-43,2
Balancer 9431-9433	BA9431-9433	15-35	2500-3000	19,7-21,2
Balancer 9444	BA9444	80-100	2500-3000	28,5
Balancer 9452-9455	BA9452-9455	115-160	2500-3000	36,8-40,9

item no.	size	min. distance	max. torque [Nm]	input	total length [mm]	suitable sensor type	weight [kg]
30332	3/8"	30	50Nm	4kt-3/8"	350	5413-1260/50 S (Schatz)	2,7
30331	1/2"	45	150Nm	4kt-1/2"	650	5413-1200/200 S (Schatz)	4,5
36751	3/4"	62	400Nm	4kt-3/4"	610	5413-1200/500 S (Schatz)	12,8

swipe right to reveal more data!
